Doosan DV11
Main Bearing Bolts

Step 1 = 294 Nm
Step 2 = 90 degrees

Doosan DV11
Connecting Rod Bolts

Step 1 = 98 Nm
Step 2 = 90 degrees

Doosan DV11
Cylinder Head Bolts

Step 1 = 58 Nm
Step 2 = 147 Nm
Step 3 = 90 degrees
Step 4 = 90 degrees
Step 5 = 60 degrees

Doosan DV11
Displacement, Arrangement,
Bore, Stroke and Compression Ratio

Displacement
10.964 liter

Arrangement
4 cycle, water-cooled,
Turbo Charged and Intercooled

Bore
128 mm

Stroke
142 mm

Compression Ratio
17.1:1

Doosan DV11
Weight and Dimensions

Dimensions
Approx
Length = 1,206 mm
Width = 1,031 mm
Height = 1,070 mm

Weight
Approx
904 Kg
