Mitsubishi 6D34 engine bolt torques, specs, manuals

Click to Sign up for full Membership
Become a Member
Get access to all the manuals and specs at Barrington Diesel Club

Mitsubishi MMC 6D34 PDF Diesel Engine Manuals

Mitsubishi 6D34 workshop manual, 263 pages, Click to download

Mitsubishi 6D34 workshop manual supplement, 210 pages, Click to download

Mitsubishi MMC 6D34 Essential Diesel Engine Bolt Tightening Torques

Mitsubishi MMC 6D34
Main Bearing Bolts
Step 1 = 59 Nm
Step 2 = +90 ± 5 degrees

Mitsubishi MMC 6D34
Connecting Rod Bolts
Step 1 = 29 Nm
Step 2 = +90 ± 5 degrees

Mitsubishi MMC 6D34 Cylinder Head torquing sequence - click to expand

Mitsubishi MMC 6D34
Cylinder head Bolts
Step 1 = 175 Nm
Step 2 = +90 to 110 degrees

Mitsubishi MMC 6D34 Diesel Engine Specs


Mitsubishi MMC 6D34T
Arrangement
In-line 6 cylinder engine
Turbocharged
Water cooled
Overhead Valve

6D34T
Compression ratio: 16.5:1

6D34TL
Compression ratio: 18.2:1


Displacement
5.861 liter

Bore - 104.0 mm
Stroke - 115.0 mm


Mitsubishi MMC 6D34
Power
162 kW @ 2500


Weight approx:
450 kg
