Scania DC12 Essential Diesel Engine Bolt Tightening Torques



Scania DC12
Main Bearing Bolts


Step 1 = 50 Nm
Step 2 = + 90 degrees

Scania DC12
Connecting Rod Bolts


Step 1 = 20 Nm
Step 2 = + 90 degrees

Scania DC12
Cylinder Head Bolts


Stage 1 = 60 Nm
Stage 2 = 150 Nm
Stage 3 = 250 Nm
Stage 4 = +90 degrees

Scania DC12 Diesel Engine Specs



Scania DC12
Displacement, Arrangement,
Bore and Stroke


Displacement
11.7 liter

Arrangement
6-cylinder
4-stroke
turbocharged

Bore
127.0 mm

Stroke
154.0 mm

Scania DC12
Power


Generator Prime Power:
356 kW; 401 kVA @ 50 Hz; 1500 rpm
384 kW; 434 kVA @ 60 Hz; 1800 rpm

Scania DC12
Weight, Dimensions
and Compression ratio


Weight
approx:
980 kg

Dimensions
approx:
Length 1220 mm
Width 710 mm
Height 850 mm

Compression Ratio
16.0:1
