Basic specs are open to everyone and include images, displacement, dimensions and weight, essential bolt tightening torques, the characteristics of the engine like its power and torque. Essential bolt tightening torques are the main bearing cap bolt torque, the connecting rod cap bolt torque and the cylinder head bolt torques.
Crankcase Bolts step 1 = 50 Nm step 2 = +90 degrees ±5 degrees
Connecting Rod Bolts step 1 = 50 Nm step 2 = +63 degrees ±2 degrees
Cylinder head Bolts step 1 = 60 Nm step 2 = 60 Nm (repeat of step 1) step 3 = +180 degrees ±10 degrees
Crankcase Bolts step 1 = 50 Nm step 2 = +60 degrees step 3 = +60 degrees
Connecting Rod Bolts step 1 = 50 Nm step 2 = +60 degrees
Cylinder head Bolts 1st phase Bolts 1 thru 6 = 100 Nm Bolts 7 thru 10 = 50 Nm 2nd phase Bolts 1 thru 6 = + 90 degrees Bolts 7 thru 10 = + 60 degrees 3rd phase Bolts 1 thru 6 = + 90 degrees Bolts 7 thru 10 = + 60 degrees
Crankcase Bolts step 1 = 50 Nm step 2 = +60 degrees step 3 = +60 degrees
Connecting Rod Bolts step 1 = 50 Nm step 2 = +70 degrees
Cylinder head Bolts 1st phase Bolts 1 thru 6 = 130 Nm Bolts 7 thru 10 = 65 Nm 2nd phase Bolts 1 thru 6 = + 90 degrees Bolts 7 thru 10 = + 60 degrees 3rd phase Bolts 1 thru 6 = + 90 degrees Bolts 7 thru 10 = + 60 degrees 4th phase Bolts marked A = 25 Nm
Sign Up
Contact Us
Technical
Arrangement
4 cylinder turbo-intercooled
4-stroke cycle engines
Displacement 2.3 liter Bore 88 mm Stroke 94 mm Compression ratio: 18.0:1
Power
96-136 hp, 71-100 kW
@ 3000-3900 rpm
Page Revision #1.1RS 04-17
